Electric Resistance Furnace Fe Cr Al Alloy Wire Low Expansion Coefficient
General Description
FeCrAl Alloy, is now the most widely used in electric heating resistance alloy. With the characteristics of stable performance; anti-oxidation; corrosion resistance; low expansion coefficient; high temperature stability; excellent coil-forming ability; high surface load; uniform and beautiful surface condition without spots.
It is mainly used in electric locomotive, diesel locomotive, metro vehicle and high Speed moving car etc brake system brake resistor, electric ceramic cooktop, industrial furnace.
FeCrAl Electrictrical Resistance Heating alloys with high electrical resistivity, temperature coefficient of resistance is small, high operating temperature. good corrosion resistance under high temperature, and particularly suitable for use in a gas containing sulfur and sulfides, low price, it is widely used in industrial electric furnace, household appliances, far infrared device ideal heating material.
FeCrAl type:1Cr13AI4, 0Cr21AI4, 0Cr21AI6, 0Cr25AI5, 0Cr21AI6 Nb, 0Cr27AI7Mo2 etc.Series electric flat belt, electric fire wire
Nickel chromium alloy with iron resistance electrothermal high resistivity, surface body sexual well. At high temperature and high intensity, and a good performance and processing may welding nature widely used metallurgical, electrical, mechanical components and electrical manufacturing industries for doing heat resistance material. Ni-Cr Type:Cr20Ni80,Cr15Ni60, Cr20Ni35, Cr20Ni30, Cr25Ni20 etc.Series electric flat belt, electric fire wire.
Product size:
wire dia.0.05-12mm; flat strip thickness 0.03-5mm,flat strip width0.2-500mm.
With features of high resistance, cheap price, high eorking temperature, good corrosion resistance especially under high temperature, good performance of anti-carburizing and far-infrared devices.
Packing: Spool, coil, carton, wooden case,container with wrapping material according to per client´s requirements.
Advantages: 1). Pass: ISO9001 certification, and SO14001certification;
2). Fine after-sale services;
3). Small order accepted;
4). Stable properties in high temperature;
5). Fast delivery
Iron Chrome Aluminum |
|
OCr25Al5 |
CrAl25-5 |
|
23.0 |
71.0 |
|
6.0 |
|
OCr20Al5 |
CrAl20-5 |
|
20.0 |
75.0 |
|
5.0 |
|
OCr27Al7Mo2 |
|
|
27.0 |
65.0 |
0.5 |
7.0 |
0.5 |
OCr21Al6Nb |
|
|
21.0 |
72.0 |
0.5 |
6.0 |
0.5 |
Iron Chrome Aluminum |
|
|
OCr25Al5 |
Can be used in operating conditions up to 1350°C, although can become embrittled. |
Heating elements of high temperature furnaces and radiant heaters. |
OCr20Al5 |
A ferromagnetic alloy which can be used at temperatures up to 1300°C. Should be operated in dry surroundings to avoid corrosion. Can become embrittled at high temperatures. |
Heating elements of high temperature furnaces and radiant heaters. |
